11/05/2013

TX e RX de IR

R1270 ohm resistor
R210k resistor
LED1Infrared LED
Q1Infrared-sensitive photoresistor

Mine Amplificador de 10w.


R1 : 6 Ohm
R2 : 220 Ohm
R3 : nothing
R4 : 10 KOhm pontesiometer
C1 : 2200 uF / 25V
C2 : 470 uF / 16V
C3 : 470 nF / 63V
C4 : 100 nF
C5 : nothing
C6 : nothing
IC1 : TDA 2003
